Chain Blocks

OzBlok chain blocks are versatile, safe and easy to use are ideal for many industrial applications. Lifting Gear Hire and Sales offer the complete range of high quality manual chain blocks to meet your most demanding needs. Buy or hire we have the right solution for you.

Download Specifications
  • High Quality
  • Great Service
  • Lifting & Rigging Experts

Chain Blocks Hire and Sale

Chain Blocks from Lifting Gear Hire & Sales proudly supplying the OzBlok brand of lifting equipment. OzBlok was launched in 1982 and has been in use in a variety of lifting applications for more than 25 years. We have an extensive range of quality OzBlok products – Chain Blocks, Lever Hoists, Plate Lifting Clamps, Girder Clamps and Trolleys. Alternatively chain hoist rental is often a cost effective option to purchase.

Features:

  • Lightweight robust construction
  • Super strength alloy loadchain
  • Fully machined liftwheel
  • Minimum headroom
  • Minimum effort to raise maximum load
  • Cast steel safety latches
  • Lower hook complete with thrust race
  • Fully enclosed gear train
  • Weather protected automatic Weston brake with unique twin pawls
  • Galvanised hand chain as standard
  • Durable baked enamel paint protection stainless steel labels

We have blocks available ranging from 0.5t to 50t capacity.

Hire Fleet

WLL 0.5t 1t 1.5t 2t 3t 5t 10t  20t 30t 50t
Standard lift 3m 3m 3m 3m 3m 3m 3m  3m 3m 3m
Falls of chain 1 1 1 1 2 2 4 8 12 22
Effort to lift WLL 23kg 30kg 32kg 35kg 27kg 41kg 39kg 42kg x 2 42kg x 2 42kg x 2
Net weight 10kg 12kg 13kg 22kg 32kg 46kg 68kg 193kg 225kg 1092kg
Loadchain diameter 6mm 6mm 8mm 8mm 10mm 10mm 10mm 10mm 10mm 10mm
